Introduction
*Bluetooth low energy technology (hereafter referred to as "Bluetooth")
Caution
Connect via Bluetooth
1. Confirm the smartphone's settings.
2. Download Camera Connect from the Google Play and install it on the smartphone.
3. Press the button.
Caution
When the [Nickname] screen appears, press the button.
Caution
4. Press the button.
5. Use the zoom lever to choose the tab.
6. Press the / buttons to choose [ 5 ].
7. Press the / buttons to choose [Wireless communication settings], then press the button.
8. Press the / buttons to choose [Bluetooth function], then press the button.
9. Press the / buttons to choose [Bluetooth function] again, then press the button.
10. Press the / buttons to choose [Smartphone], then press the button.
11. Press the / buttons to choose [Pairing], then press the button.
12. Press the / buttons to choose [Do not display], then press the button.
13. A message is displayed indicating that pairing is in progress.
14. Touch the [ Camera Connect ]( ) application icon on the smartphone to start Camera Connect.
15. After the camera is recognized, a camera selection screen is displayed.
16. Press the / buttons to choose [OK], press the button.
17. Press the button of this screen.
Caution
18. Choose [Images on camera] in Camera Connect.
19. Use the smartphone to import images from the camera to the smartphone.
20. After the screen refreshes, choose the desired images (), and then touch [ ] on the bottom of the screen ().
Caution
21. After the images have been saved, touch [ ] appearing in the upper right of the screen.
22. Touch [ ] in the upper left of the screen to return to the menu screen.
23. To end the connection, touch the [ ] icon displayed in the upper right of the screen.
24. Touch [Yes].
Connect via the Wi-Fi Menu
1. Confirm the smartphone's settings.
2. Download Camera Connect from the Google Play and install it on the smartphone.
3. Press the button.
Caution
When the [Nickname] screen appears, press the button.
Caution
If the following screen appears, press the / buttons, the screen for step 4 will appear.
4. Press the / buttons to choose [ ], then press the button.
5. Press the / buttons to choose [Register a device for connection] , press the button.
6. Press the / buttons to choose [Do not display] , press the button.
7. The SSID ( ) and password ( ) will be displayed on the screen.
8. Turn Wi-Fi settings to ON in your smartphone, choose the SSID ( ) from step 7.
9. Input password from step 7 ( ).
10. Once the connection between the camera and the smartphone has been confirmed, press the home button to return to the home screen.
11. Touch the [Camera Connect] ( ) application icon on the smartphone to start Camera Connect.
12. After the camera is recognized, a camera selection screen is displayed.
13. Press the / buttons to choose [OK] , press the button.
14. The camera screen will show [Wi-Fi on].
15. Choose [Images on camera] in Camera Connect.
16. Use the smartphone to import images from the camera to the smartphone.
17. After the screen refreshes, choose the desired images (), and then touch [ ] on the bottom of the screen ().
Caution
18. After the images have been saved, touch [ ] appearing in the upper right of the screen.
19. Touch [ ] in the upper left of the screen to return to the menu screen.
20. To end the connection, touch the [ ] icon displayed in the upper right of the screen.
21. Touch [Yes].
Using the On-Screen Keyboard
Use the on-screen keyboard to enter information. Note that the length and type of information you can enter varies depending on the function you are using.
•Entering characters Press the / / / buttons to choose the key of your desired character, and then press the button. | |
•Moving the cursor Choose [ ] or [ ] and press the button. | |
•Switching input modes Choose [ ], press the button to switch to capital letters. Choose [ ], press the button to switch to numbers or symbols. | |
•Deleting characters Choose [ ] and press the button. The previous character will be deleted. | |
•Confirming input After pressing the button, press the / buttons to choose [OK], press the button. |
Caution
