CJ20eX5B IASE S

CJ20eX5B IASE S Broadcast Lens

Portable 4K UHD broadcast zoom lens

4K Optical Performance and HD Imaging Quality

Image of a golfer in action taken using the CJ14eX4.3B IASE S Broadcast Lens

HDR delivers excellent gradation representation and enhanced realism and dimension, including texture, for realistic image representation. Canon's 4K UHDxs lenses deliver the advanced optical performance essential for a 4K+HDR system lens, helping to enable shooting of more realistic and immersive images.

5mm Wide Angle with Powerful 20x zoom

With a wide-angle focal length of 5 mm and powerful 20x zoom, the CJ20ex5B can deliver a beautiful panoramic image, as well as tight shots with amazing detail, making it a great fit for a wide variety of applications including television news, sports and studio shooting.
Compact and lightweight

Despite its impressive 5.0-100mm focal range, the lens weighs in at only 2.15kg. The portable CJ20ex5B 4K UHDxs lens is similar in size to Canon's other 2/3" HD lenses, while delivering 4K UHD performance and offering the mobility demanded in the reporting and documentary fields.

Specifications and brochure

Focal Length

5-100mm, 10-200mm

Maximum Aperture (f)

1:1.8 (5 -61mm) 1:2.95 (100mm), 1:3.6 (10 - 122mm) 1:5.9 (200mm)

Dimensions (mm – retracted)

166.3 x 110.8 x 251.7 mm

Weight (g)

2.16kg

Extender

1.0x, 2.0x

Zoom Ratio

20x

Angular Field of View

87.7° x 56.7° (5mm) 5.5° x 3.1° (100mm), 51.3° x 30.2° (10mm) 2.1° x 1.2° (200mm)

M.O.D.

0.4m

Shooting Range at M.O.D.

87.1 x 49cm (5mm) 4.2 x 2.4cm (100mm), 43.6 x 24.5cm (10mm) 2.1x1.2cm (200mm)
